Features

• Air Purification
• Super IFD Filter
• Wide Voltage Range With Hyper PCB
• Performance Specifications

• Capacity wise:    1.5-Ton
• Category wise: DC Inverter
• Color: Golden
• Cooling Capacity BTU:19000
• Running Current Cooling (A):2.3 ~9.2
• Power input Cooling (KW):0.41 ~ 2.3
• Heating Capacity BTU:19500
• Running Current Heating (A):2.4 ~10.3
• Power Input Heating (KW):0.42 ~ 2.25

Other Parameters

• Input Power Supply (Ph, VAC, Hz):1PH,220V ?, 50Hz
• Air Flow Volume (m3/h):1150
• Refrigerant Type: R-32
• Refrigerant Amount (G):1000

Indoor & Outdoor Parameters

• Indoor Net Dimension (L*W*H) mm³:1045*230*335
• Indoor Packing Net Dimension (L*W*H) mm³):1160*347*455
• Indoor Net Weight (kg):13.6
• Indoor Gross Weight (kg):20
• Outdoor Net Dimension (L*W*H) mm³:820*300*610
• Outdoor Packing Net Dimension (L*W*H) mm³:955*418*670
• Outdoor Net Weight (kg):29
• Outdoor Gross Weight (kg):37

Features

• Cooling: Yes
• Heating: Yes
• Dry: Yes
• Vertical Flapper Auto Swing: Yes
• Horizontal Louvers Auto Swing: Yes
• Air-Purification: Yes
• WiFi: Yes
• Self-Clean: Yes
• Anti-Corrosion: Yes
• Turbo Function: Yes
• UPS Enable: Yes

Accessories

• Installation Kit (Liquid side) Material*Length*Dia*Thickness (mm):Copper * 2920*6*0.65 (6mm)
• Installation Kit (Gas side) Material*Length*Dia*Thickness (mm):Copper * 2920*12*0.65 (12mm)
• Power Cable (Core*mm²):3*2.5
• Communication Cable b/w Indoor & Outdoor (Core*mm²):4*1.5

Warranty

• Compressor:10 Years
• PCB Kit:4 Years
• Evaporator: 3 Years
• Parts:1 Years
