Features:

• Characteristics Angle adjustable Large screen, easy to read
• Full protection design against burn
• Data hold function for easy reading after measurement
• With PVC shockproof holster
• With double fuse, safe and reliable
• Technology Features
• DCV: 200m-2-20-200-1000V ±0.5%
• ACV: 200m-2-20-200-750V ±1.0%
• DCA: 2m-20m-200m-20A ±1.8%
• ACA: 2m-20m-200m-20A ±2.0%
• OHM: 200-2k-20k-200k-2M-20M?-200M? ±1.0%
• Cap: 20n-200n-2u-20u-200uF ±4.0%
• General Description
• 3.5" digit LCD, Max display 1999
• Low-Voltage Display
• Diode Testing: Display Approximate Voltage
• Overload protection: yes
• Audion Testing: yes
• Continuity Buzzer:yes
• Auto power off:yes
• Data hold: yes
• Max display: 1999, Automatic polarity display
• All ranges fully protected.
• Diode assembly test / Transistor P-N junction test/Transistor hFE test
• Continuity test with buzzer sound in circuit.
• Low battery voltage indication.
• Automatic power off.
• Data hold function.
• Electric circuit protection.
• Specifications:
• Model:DT9025A
• Measuring range:
• Max AC Current:20A
• Max AC Voltage range:750V
• Max DC Voltage range:1000V
• Resistance Measurement:200 Ohm-2000M Ohm range
• Scale degree amp,Accuracy:
• Showed as in the table
